Online Conductivity Controller with Conductivity Range 0 to 20.00, 200.0, 2000 µS/cm, 20.00, 200.0 MS/cm TDS Range 0 to 10.00, 100.0, 1000ppm, 10.00, 200.0 PPT 4 to 20mA Outputs

SpecificationsConductivity●Range:0 to 20.00, 200.0, 2000 µS/cm, 20.00, 200.0 mS/cm●Resolution:0.001, 0.01, 0.1, 1, automatic●Accuracy:±1% F.S.●Calibration:1 to 3 points●Calibration Solutions:10 µS / 84 µS / 1413 µS / 12.88 mS / 111.8 mSTDS●Range:0 to 10.00, 100.0, 1000ppm, 10.00, 200.0 ppt●Resolution:0.01, 0.1, 1, automatic●Accuracy:±1% F.S.●TDS Conversion Factor:0.1 to 1.0 (default 0.5)Temperature●Range:0 to 100°C / 32 to 212°F●Resolution:0.1°C/°F●Accuracy:±1°C / ±1.8°F●Calibration:1 point●Calibration Range:Reading ±10°C Communication●Signal Output:4 to 20 mA●High/Low Limit Alarm:0.02 uS/cm to 20.0 mS/cm, selectable●Load:Maximum 500 Ω●Communication Interface:RS485●Connection Terminals:Detachable screw terminalsOther Specifications●Temperature Compensation :0 to 100°C / 32 to 212°F, automatic●Temperature Coefficient:0.0 to 10.0%/°C●Reference Temperature:25°C●Cell Constant:K=0.1 / 1 / 10●Environmental Conditions:0 to 50°C / 32 to 122°F, relative humidity <80%●Power Supply:DC 24V●Dimensions:96 × 96 × 75 mm●Weight:360g

• Economical online conductivity controller comes with a platinum cell conductivity electrode.
• 1 to 3 points calibration with automatic recognition for conductivity standards.
• Selectable cell constant, temperature coefficient and TDS conversion factor.
• Automatic temperature compensation ensures accurate readings over the entire range.
• Setup menu allows setting the number of calibration points, alarm limits, hysteresis value, 4 to 20 mA output, etc.
• Reset function automatically restores all settings to the factory defaults.
